Grandstream GSC3615 IP Camera
Key Features
Brand: Grandstream
Supports motion detection
Smart infrared technology for optimal white balance and exposure
Built-in PoE to power the device and provide a network connection
Supports alert notifications via outbound voice or video call & email screenshot
IP67-level weatherproof capability
Primary stream 1920×1080 and Secondary stream 640×480
SIP/VoIP support for video and audio streaming to endpoints (external microphone required)
1 Year Warranty
Grandstream GSC3615 Infrared Weatherproof Bullet IP Camera
The Grandstream GSC3615 is an infrared weatherproof bullet IP camera designed for wall-mounted or ceiling-mounted security surveillance . This network hardware functions as a standalone monitoring node. It integrates with existing business local area networks, network video recorders, and unified communication platforms to deliver continuous property surveillance without requiring a dedicated external control unit
Hardware and Lens Specifications
The physical layout combines a durable exterior bullet housing with a high-definition image sensor and an array of diagnostic infrared illumination lamps. This configuration ensures clear visual tracking during both daytime hours and pitch-black night conditions.
Visual Performance and Camera Sensor
The internal optics utilize progressive scan technologies to capture moving objects cleanly without motion blur.
- Resolution Support : Captures real-time video streams up to 1080p Full High Definition resolution at 30 frames per second.
- Image Sensor : Built with a 1-over-2.9 inch progressive scan complementary metal oxide semiconductor sensor.
- Lens Optics : Equipped with a 3.6-millimeter fixed focal lens.
- Light Sensitivity : Operates in low-light environments down to 0.01 Lux before transitioning into night mode.
Night Vision and Lighting Array
The camera handles around-the-clock facility monitoring by tracking dark outdoor zones using automated lighting mechanisms.
- Infrared Illumination : Contains an integrated array of infrared light emitting diodes.
- Visual Range : Supports night vision tracking distances up to 20 meters in total darkness.
- Smart Filtering : Utilizes a physical infrared cut filter that switches automatically based on ambient room light changes.
Structural Build and Weather Protection
The physical bullet housing uses industrial components designed to resist fluid intake and allow precise directional aiming.
- Weather Resistance : Certified to IP67 environmental protection standards to guard internal circuitry from rain and dust.
- Operating Range : Built to operate in extreme thermal environments ranging from negative 20 degrees up to 50 degrees Celsius.
- Casing Type : Features a traditional bullet structure with an adjustable 3-axis mounting bracket for precise wall or ceiling targeting.
Connectivity and Interface Options
The hardware tailors to clean installation methodologies by streamlining data and power delivery into a single connection point.
Wired Network and Power Input
- Network Interface : Built with a single 10 out of 100 Megabits per second RJ45 Ethernet port.
- Power over Ethernet : Configured with Power over Ethernet support via standard 802.3af Class 3 parameters.
- Local Power : Includes an auxiliary 12-Volt direct current power input jack for networks lacking Power over Ethernet switches.
Internal Audio Hardware
Unlike traditional video-only surveillance units, this bullet camera captures local acoustic data without separate microphone accessories.
- Audio Input : Contains a built-in internal microphone to capture vocal streams and yard sounds.
- Audio Codecs : Encodes audio data using standard telecommunication codecs for network streaming efficiency
