Dell 300GB 10k SAS 2.5″ 6Gbps Server Hard Drive
Key Features
Brand: Dell
Model: Dell 300GB 10K SAS 2.5″ 6Gbps
Capacity: 300GB
Form Factor: 2.5-inch
Interface: SAS (Serial Attached SCSI) 6Gbps
Drive Speed: 10,000 RPM
Data Transfer Rate: Up to 6 Gbps (SAS 6 Gbps)
Drive Type: Enterprise hard disk drive
Hot Swap Capability: Yes (supports hot swapping)
Power Consumption: Typical operational power around 7.0W
Operating Temperature: 5°C to 55°C (41°F to 131°F)
MTBF (Mean Time Between Failures): 1,400,000 hours
Cache Size: 64MB
Interface Connector: 6G SAS connector
1 Year Warranty
Dell 300GB 10K SAS 2.5 Inch Hard Disk Drive Review: Mission-Critical Storage
The Dell 300GB 10K SAS 2.5 Inch 6Gbps Server Hard Drive delivers high-velocity data processing and continuous operational reliability engineered specifically for enterprise server environments. This enterprise-class small form factor drive optimizes random access performance while maintaining the robust structural data integrity required by high-availability corporate datacenters.
Executive Overview and Premium Design Philosophy
The Dell 300GB 10K SAS enterprise drive represents a core standard in high-velocity performance for localized computing infrastructure. It transitions organizations from low-durability consumer storage drives to a fully validated enterprise storage ecosystem. Designed for deployment in high-density PowerEdge rack servers, transactional business database arrays, and storage area networks, this original equipment component safeguards mission-critical business data from unexpected hardware delays.
Engineered for Elite Professional Workflows
Continuous high-speed data retrieval is an absolute requirement for active business web application servers, transaction processors, and operating system boot pools. This mechanical drive facilitates this necessity by pairing a high-velocity 10000 RPM spindle speed with the professional Serial Attached SCSI communication protocol. IT networks can handle intense block-level data transactions and continuous daily read-write cycles without experiencing hardware degradation or interface communication bottlenecks.
Structural Integrity and Premium Aesthetics
Constructed with a heavy-duty metallic chassis and a reinforced internal spindle assembly, this internal drive module slides seamlessly into standard 2.5-inch small form factor hot-swap server bays. Unlike budget desktop hard disks that fail under constant vibrations, this premium enterprise assembly features advanced internal vibration-dampening mechanics. The industrial design manages internal rotational physics efficiently, keeping multi-drive server chassis running reliably under peak processing demands.
Key Technical Specifications
-
- Formatted Data Capacity: 300 Gigabytes of raw storage space
- Spindle Rotational Speed: 10000 Revolutions per minute operational rate
- Hardware Interface Standard: 6 Gigabits per second Serial Attached SCSI Gen 2
- Physical Drive Form Factor: 2.5 Inch Small Form Factor configuration
- Compatible Part Numbers: G156M, H8799, C975M, J530M, and 0H8799
- Integrated Cache Buffer: 16 Megabytes or 64 Megabytes high-speed volatile data memory
- Sector Architecture Profile: Standard Native 512n physical layout
- Deployment Class Status: Enterprise Mission-Critical high-availability reliability
Top Benefits of the Dell 300GB 10K SAS 6G Drive
Professional High-Speed 6Gbps Data Pipeline
The generation two SAS interface provides a substantial 6 Gigabits per second maximum data transfer rate threshold. This advanced throughput level allows the storage drive to communicate with host bus adapters and hardware RAID controllers smoothly, speeding up system rebuilds, handling concurrent inputs, and accelerating server boot paths.
High-Velocity 10K RPM Input Output Execution
Operating at 10000 Revolutions per minute significantly lowers mechanical data seek times compared to standard 7200 RPM enterprise drives. This fast rotation speed enables faster random read and write performance, making it highly effective for hosting localized hypervisor boot files, email exchanges, and transaction processing systems.
Advanced Dual-Port Signal Paths for Fault Isolation
The enterprise-class Serial Attached SCSI architecture features dual-port signal routing capabilities to maintain high system availability. If a primary data path, controller cable, or motherboard pipeline experiences an unexpected signal drop, the drive can route data packets over a backup line instantly, preventing service downtime.
True Hot-Swappable Hot-Plug Operational Safety
Engineered to operate inside critical enterprise equipment configurations, this hard drive fully supports real-time hot-plug mechanical replacements. System technicians can extract a degraded drive module from a live RAID array and slide this fresh expansion replacement into place without resetting the operating system or scheduling emergency work windows.
Server Storage Form Factor Allocation Matrix
| Chassis Drive Configuration | Compatibility Validation | Mounting Frame Requirement |
|---|---|---|
| 2.5 Inch Small Form Factor Bay | Fully Compatible | Mounts Directly Inside Standard 2.5 Inch Caddy |
| 3.5 Inch Large Form Factor Bay | Partially Compatible | Requires 2.5 Inch to 3.5 Inch Hybrid Adapter Bracket |
Step-by-Step Server Hardware Installation Instructions
-
- Mount Drive Into the Carrier: Position the 2.5-inch drive inside an authorized metallic caddy carrier and secure the side retaining screws
- Identify Target Storage Slot: Check your running storage controller dashboard or server front panel to identify an empty or failed drive slot.
- Open Carrier Security Latch: Press the plastic button on the front of your drive tray to spring the vertical security latch handle outward.
- Slide Drive Into Server Bay: Push the carrier firmly into the open server bay channel until the internal SAS port clicks into the midplane.
- Lock the Front Security Handle: Push the vertical caddy handle flush against the server frame to complete lock engagement and initiate automated array syncing.
Frequently Asked Questions
Can this SAS drive connect directly to a standard desktop SATA port?
No. This 6G enterprise drive requires an authorized server SAS controller card or a dedicated server midplane to communicate. While Serial Attached SCSI backplanes found in enterprise servers can accept standard consumer SATA hard drives, standard desktop SATA motherboard ports cannot process the communication protocols used by commercial SAS drives
What is the advantage of 10K RPM over 7.2K RPM drives?
The 10000 RPM rotation profile delivers faster read-write speeds and lower input-output latencies. This makes it ideal for operating system boot drives and heavy database performance. In contrast, 7.2K RPM drives prioritize larger raw storage volumes at a lower price point but operate with slower data search times]
Does this unit come pre-installed with the hot-swap tray?
Retail choices depend on the specific part number bundle you order. Many versions are shipped as bare drives to give you deployment flexibility across different mounting brackets, while specialized option kits include pre-mounted PowerEdge generation caddies to speed up installation inside matching server arrays.
