Cisco Meraki MS120-24P Cloud Managed Switching
Key Features
Brand:CISCO
Gigabit Access switching with 24- and 48- port models and PoE+
4 x 1G SFP uplink interfaces on all models
Non-blocking switch with up to 104 Gbps bandwidth support
Fanless design on select models
Up to 740 watt PoE budget with PoE+ support and dynamic power allocation for powering APs, phones, cameras, and other PoE-enabled devices
8 dedicated QoS queues for converged voice, video, and data applications
Low power consumption, quiet acoustic design, and shallow rack depth options, enabling flexible deployment in wiring closets as well as offices and classrooms
Integrated mounting brackets for rack mounting
1 Year Warranty
Meraki Cisco MS120-24P Cloud Managed PoE Switch Product Overview
The Cisco Meraki MS120-24P balances high-density Power over Ethernet (PoE) delivery, Layer 2 network switching efficiency, and cloud-managed operational simplicity. Featuring twenty-four gigabit ethernet ports and a robust three hundred and seventy watt power budget, this rack-mountable network chassis serves as an ideal solution for small-to-medium enterprise branches and growing retail facilities. Designed to consolidate edge switching and device power delivery into a single physical unit, this switch ensures smooth local area network data throughput without needing separate standalone power injection equipment.
Modern corporate environments require massive power capacity and deep local traffic visibility, and this cloud-managed switch delivers on both fronts. It seamlessly handles demanding data traffic workflows including voice over internet protocol routing, internet protocol surveillance streaming, and high-density wireless access point connections. By combining automated centralized cloud management with integrated remote diagnostic tools, it eliminates traditional performance bottlenecks during peak network usage. Whether you are building a campus network for corporate desktop configurations or securing a localized infrastructure for retail store operations, this Cisco Meraki switch provides enterprise-grade engineering in a robust physical form factor
Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | MS120-24P |
| Switch Layer | Layer 2 Functionality |
| Physical Ports | Twenty Four Gigabit Ethernet Ports |
| Uplink Interfaces | Four One Gigabit SFP Fiber Ports |
| PoE Power Budget | Three Hundred and Seventy Watts |
| PoE Type | IEEE 802.3at PoE and 802.3af PoE Support |
| Switching Capacity | Fifty Six Gigabits Per Second |
| Management Protocol | Centralized Cisco Meraki Cloud Dashboard |
Core Product Capabilities
Heavy Duty PoE Power Budget
-
- Provides up to thirty watts of electrical power per physical local port
- Allocates three hundred and seventy total watts dynamically across all lines
- Eliminates the need for local wall outlets or separate power injection bricks
- Powers high-draw client devices like pan-tilt-zoom cameras and video phones directLY
High Bandwidth Fiber Uplinks
-
- Incorporates four dedicated one gigabit SFP interface slots
- Enables long-distance fiber connections to core distribution network layers
- Bypasses traditional traffic bottlenecks heading out to primary routers
- Preserves all twenty-four copper ports for local user device connections
Continuous Cloud Diagnostic Tracking
-
- Running automatic cable testing tools to identify physical wire faults remotely
- Real-time packet capture utilities accessible straight from a web browser
- Instant alert notifications sent automatically via email during port dropouts
- Simplifies routine hardware troubleshooting across distributed company locations
Performance and Workflow Optimization
Automated Cloud Port Orchestration
The cloud-managed switch chassis utilizes advanced software architectures to automate deployment configurations. This software-defined framework allows network managers to clone port settings, apply uniform security tags, and push global configuration profiles across hundreds of switches simultaneously, optimizing network setup times for extensive enterprise branches.
Smart Device Recognition Technology
Mobile and remote company expansions benefit directly from the hardware design. Operating with intelligent device profiling enables the switching system to automatically recognize attached hardware like phones, printers, and cameras. This technical versatility ensures that the correct virtual local area network tags are applied instantly without manual port configuration.
Data Security and Quality of Service Protocols
Unified Enterprise Access Control
Information protection remains a primary structural benefit of this cloud infrastructure. The integrated software platform employs standard 802.1X port security, automated MAC address filtering, and guest network assignment rules to block rogue connections automatically. This defense mechanism ensures that your corporate records and local database assets resist unauthorized access.
Voice and Video Traffic Prioritization
Hardware reliability is reinforced through dedicated internal quality of service engines. The system identifies critical voice over internet protocol packets instantly, routing them through high-priority queues without pulling processing power away from everyday web traffic. This automated protective workflow guards business communications against voice dropping or video stuttering.
Network Architecture Utilization Guidelines
High Density Edge Access Layer
The twenty-four port layout provides excellent real estate for busy corporate floor plans. It comfortably links entire clusters of employee desktop computers, network printers, and local storage servers into a cohesive, high-speed mesh, eliminating the performance drag associated with daisy-chaining smaller unmanaged office switches.
Centralized Surveillance and Voice Hub
For distributed retail setups, this intelligent switch offers a reliable platform to consolidate infrastructure hardware. Technology support groups can configure power schedules to reboot surveillance cameras automatically during off-hours straight from the main operating system dashboard, keeping retail facilities safe with minimal physical site visits.
Primary User Benefits
Lower Capital Infrastructure Costs
The switch enables corporate finance managers to lower physical hardware costs. This hardware convergence layer ensures that missing network elements like external power injectors, individual wall adapters, and local site controllers are resolved efficiently within a single rack slot.
Standardized Rack Mountable Form Factor
The standardized physical body slides smoothly into standard nineteen-inch network server enclosures. The efficient structural chassis features internal cooling fans to maintain proper airflow, ensuring zero thermal interference inside tightly packed equipment closets or busy corporate server rooms.
Unified Dashboard Management Software
The device works in tandem with the proprietary Cisco Meraki cloud orchestration platform. Users can evaluate baseline traffic statistics, monitor individual port power consumption trends, execute secure automated firmware upgrades, and track overall hardware health from a unified graphic interface
Target Audience Use Cases
Corporate Network Administrators
Network professionals handling distributed retail storefronts, secure banking endpoints, and medical clinic infrastructure can depend on the hardware reliability. The cloud architecture allows engineering teams to push uniform switch port configurations across thousands of branch offices instantly.
Growing Small to Medium Businesses
Evolving corporate operations requiring enterprise security protocols can unlock full data protection without separate device complexity. The modular SFP slots allow budget-conscious tech buyers to run high-speed fiber lines to other rooms as company headcounts expand.
